| Brand Name : | JSSCD |
| Model Number : | JSSCD-260NC/P |
| Delivery Time : | 7-60 work days |
| Certification : | HB24Q00435R0S HB24E0025 HB24S00242R0S8R0S |
| Payment Terms : | FOB |
| Supply Ability : | 500 Sets Per Year |
This high-performance CNC circular saw is engineered for rapid and accurate metal profile cutting, specializing in horizontal operations. Its integration of swift cutting technology, automated control, exacting standards, and eco-friendly operation has established it as a critical asset in contemporary metal fabrication lines, renowned for its dependable performance.
Designed for precision cutting of diverse profiles like round tubes, angle iron, and square sections, the machine features versatile clamping mechanisms (hydraulic horizontal/vertical). This minimizes fixture adjustments, significantly boosting flexibility when handling materials of varying dimensions and forms.
Key features include:
| Model | Unit | JSSCD-260NC/P |
|---|---|---|
| Mainframe dimensions | mm | 2600*2700*2300 |
| Bar & round pipe | mm | 110-260 |
| Angle bar & square bar | mm | 110-230 |
| Saw blade size | mm | φ750*3.8*φ80 |
| Pin holes and hole diameters | mm | 4*φ24*150 φ80 |
| Spindle motor power | KW | 37(6P)/30(6P) |
| Spindle speed | rpm | 20-60 |
| Feed servo motor power | KW | 7.5 |
| Feeding servo motor power | KW | 3.5 |
| Material removal length at the front end | mm | 20-99 |
| Single feeding length(repeatable) | mm | 10-800 |
| Hydraulic drive motor power | KW | 7.5 |
| Rated pressure of the hydraulic system | mpa | 7.5 |
| Hydraulic oil capacity | L | 150 |
Q1: Are you a manufacturer or a trading company?
A:We are a professional manufacturer of saw blade grinders. We have a 30,000 square meter factory and a team of dedicated technicians specializing in design, manufacturing, and sales.
Q2. Where is your factory located?
A:Our factory is located in Nantong City, Jiangsu Province, China.
It will takes about 1.5 hours from Shanghai Hongqiao station to our city
Q3: What is your factory acceptance test method?
A: You can send us sample material to be cut, and we will perform a test cut using our machine. After the test is complete, we will provide you with detailed cutting data. (We will also send you a video of the machine cutting operation for your confirmation.)
Q4:What is your method of transaction?
A:We adopt the FOB(Free ON Board) transaction.
Q5: How about your delivery time?
A: Generally, it will take 7-60 work days after receiving your order.
The specific delivery time depends on the items and the quantity of your order.
Q6:How about the payment term
A:T/T 30% deposit, 70% of balance paid before shipment. (For other payment methods please contact our sales team)
Q7:Does the band saw blade have any international certifications?
A:Yes,we have obtained CE,ISO international certification.
|
|
